Zoom 5354 - Event Log


56
Table 4. Diagnostics Menu Option
Option Description
Utility
Select the utility for troubleshooting.
Parameters
Enter the required parameters to perform diagnostics.
Start Test
Click this button to begin diagnostic after making any changes to the
default parameters.
Abort Test
Click this button to abort Ping diagnostics.
Clear Results
Click this button to clear the results table.
Event Log
The Event Log page is useful when you are working with your cable provider to debug
your Cable Modem/Router. Most users can ignore this page.
To access the Event Log page, click Status in the menu bar and then click the Event
Log submenu. Figure 9. Example of Event Log Page shows an example of the page.
Figure 9. Example of Event Log Page
