RT100RoughTerrainCrane 06-1
ThispartofthechapteristoshowyouthecontrolsandinstrumentsontheRT100roughterrain
crane.Thisisonlyasmallpartofthedatathatyoumustknowbeforeyoucansafelyoperate
thecrane.Donotoperatethecraneuntilyouaretrainedinalltheothersectionsofthismanual.
6.1UPPERCONTROLSANDINSTRUMENTS
1 2 3 4 5 6 7 8 9 10 11
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29
Figure06 – 1 UpperControlsandInstruments
1. High/LowSpeedSelectSwitchforMainWinch
2. SteeringSwitch
3. CameraDisplay
4. High/LowSpeedSelectSwitchforAux.Winch
5. AirConditionerControlPanel
6. A/CFanSpeed/MasterSwitch
7. CabHeaterPowerSwitch
8. CabCoolerPowerSwitch
