RT60 Rough Terrain Crane 07 - 11
EXTEND THE OUTRIGGERS
a) Remove the outrigger beam retaining pin.
b) Push and hold 2 or 4 outrigger switches to the “BEAM” position.
1 Push and hold the outrigger extend / retract master switch to the “EXTEND”
position.
2 After the outriggers move to the “FULLY” or “INTERMEDIATELY” marks,
release the master switch. The switch moves to the neutral position
automatically.
c) After the 4 outrigger beams extend to the correct positions, push and hold the 2
front (or rear) outrigger switches to the “JACK” position.
1 Push and hold the outrigger extend / retract master switch to the “EXTEND”
position.
2 After the 4 outriggers hold the weight of the crane (wheels off the ground),
release the master switch. The switch moves to the neutral position
automatically.
d) Make the crane level.
1 Look at the bubble level to tell if the crane is at level.
2 If the bubble indicator does not show a level indication, you can move each
outrigger to make the crane level.
e) For example:
If the crane is low on the right front, do the steps that follow:
1 Push the right front outrigger switch to the “JACK” position.
2 Push the outrigger extend / retract master switch to the “EXTEND” position at
the same time.
3 Monitor the bubble indictor. When the bubble is at the correct position, release
the switches.
f) Install the outrigger retaining pins.
RETRACT THE OUTRIGGERS
Retract the boom and attach it to the support before you retract the outriggers.
a) Remove the outrigger beam retaining pins.
b) Push and hold 2 front (or rear) outrigger switches to the “JACK” position.
1 Push the outrigger extend / retract master switch to the “RETRACT” position
at the same time.
2 After the 2 front (or rear) outrigger jacks fully retract, release the master switch.
Warning
