The switch moves to the neutral position automatically.
3 Do this step until all 2 front (or rear) outrigger jacks are retracted.
c) Push an outrigger switch (1 of 4) to the “BEAM” position.
1 Push the outrigger extend / retract master switch to the “RETRACT” position
at the same time.
2 After the outrigger retracts fully, release the master switch. The switch moves
to the neutral position automatically.
3 Do this step until all 4 outriggers are retracted.
d) Install the outrigger retaining pins.
INSTALL AND REMOVE THE OUTRIGGER FLOATS
a) Installation
Before you extend the outriggers, remove the socket pin from the outrigger floats and
pull out the outrigger floats. When the hole aligns with the vertical cylinder, install the
socket pin.
b) Removal
After you fully retract the outriggers, remove the socket pin and push in the outrigger
float until it in the correct position. Install the socket pins.
Before you move the outriggers, make sure that there is clearance to prevent
injury to personnel or damage to the crane and other objects.
Do not move the outriggers if you have a load off the ground.
You can adjust the speed (slow or fast) of the outriggers movement (extend
or retract) by the engine RPM (increase or decrease).
Make sure that you install the outrigger floats before you move the
outriggers.
Make sure that you remove the retaining pins before you extend or retract
the outrigger beams. After the outrigger beams are in position, install the
retaining pins.
Before you extend or retract the outriggers, make sure that the floats are
clear from all objects.
Make sure that all the tires are off the ground (crane weight held up by the
outriggers) before you start to lift a load.
When the crane is on a level area, examine the bubble indicator. The bubble
shows in the middle of the indicator. If not, adjust the nuts below the
indicator.
