RT60 Rough Terrain Crane 07 - 15
b) LIFTING HEIGHT CHART
Fig. 07 - 7
The data shown in the lifting height chart do not consider about the deflection of
boom.
Caution
Boom length: L (m)
Boom angle: About θ (°)
Supposed lifting height: About
H (m)
Supposed working radius:
About R (m)
