07-24
BOOMEXTENDING
a) Makesuretheseatoccupiedandactivatethepedaltoextendtheboom.
Figure07 19 Extend/RetractPedalForward
Onlywhentheoperatorsseatisoccupiedandtheicononthedisplaylightsup,canthe
joysticksinitiatevariousmovement.
b) Tilt the pedal forward to extend the boom. If telescoping cylinder I is
activated,telescopicsection1extends.WhencylinderIisfullyextended,LMIwill
alarm.PushbuttononLMI tochange tocylinder II.Thetelescopicsections2,3
and4moveoutatthesametime;
Fig.07-20
c) Aftertheboomextendstorequiredposition,slowlytiltthepedalbackwardtoneutral
position;
Caution
Ifthehookblockcontactstheanti-twoblockweightduringboomtelescoping,
acoustic/visualwarningwillbesentoutandthemovement Boomextending is
switchedoff.Payoutthehoistropealittleiftheboomisstillneededtobeextended.
Duringcommissioningormaintenance,theswitch-offcanbebypassedbythe
bypasskeyswitch.However,theoperationshouldbecarriedoutwithmaximum
caretopreventaccidents.
