SJ-20210621164956-008 | 2022-09-01(R1.3)
Specify the data traffic direction. The Ingress option and
egress option cannot be the same.
⚫
If the ingress is LAN, the egress should be a WAN or LTE
connection. The data traffic direction is upstream.
⚫
If the ingress is a WAN or LTE connection, the egress
should be the LAN. The data traffic direction is down-
stream.
A DSCP is specified for the TOS byte in the IP header of each
packet to indicate the priority. Range: 0–63.
3.
Click Apply button to apply the changes.
Configure the MAC filter
1.
Click MAC Filter to open the MAC filter page, see Figure 4-15.
Figure 4-15 MAC Filter Page
2.
Configure the MAC filter configuration parameters, see Table 4-7.
Table 4-7 Parameter Descriptions for the MAC Filter
The name of the MAC filter.
The default value is Routing.
Protocol of data streams. Options: IP, ARP, RARP, PPPoE
and Any.
Source MAC Address / Destination
MAC Address
MAC address that needs to be filtered.
Both options cannot be null at the same time.
