Transmission method Description
JPEG/HTTP Static JPEG image transmission. Refer to the JPEG tab
below.
MJPEG/HTTP A series of consecutive JPEG images, the Server Push –
multipart/x-mixed-replace method. Refer to the JPEG tab
below.
RTSP + RTP/UDP RTSP with separate RTP/UDP audio and video streams.
Supported both for audio (G.711) and video (H.264, H.263,
MPEG-2 and MJPEG). Refer to the RTSP tab below.
RTP/RTSP RTP tunnelling via RTSP. Supported both for audio
(G.711) and video (H.264, H.263, MPEG-2 and MJPEG).
Refer to the RTSP tab below.
RTP/RTSP/HTTP RTSP tunnelling via HTTP. Supported both for audio
(G.711) and video (H.264, H.263, MPEG-2 and MJPEG).
Refer to the RTSP tab below.
RTP/UDP-Multicast Uncontrolled RTP packet multicast. Supported for audio
(G.711) only. Refer to the Multicast tab below.
Explanation of Terms
RTP(Real-Time Transport Protocol) – is a protocol defining the standard packet format for
audio/video transmission via IP networks.2N IPintercom employs this protocol for
audio/video streaming. The RTP transport protocol is either UDP or also RTSP and HTTP.
RTSP(Real-Time Streaming Protocol)– is a network protocol for streaming server
control (controls setting up, launching and stopping of audio/video streams).
HTTP(Hypertext Transfer Protocol)– helps transmit practically any contents and is
used primarily by internet browsers for web server communication.2N IPintercom uses
the HTTP to transmit static JPEG images or MJPEG streams via the HTTP Server Push.
IP Multicast– is a way of parallel sending of IP packets from one source to multiple
stations via IP networks.2N IPintercom uses IP multicast for sending and receiving audio
streams.
ONVIF (Open Network Video Interface Forum)– is a set of video camera search,
configuration and administration specifications for the IP network. The2N IPintercoms
are ONVIF compatible and fully implement the ONVIF Profile T and Profile S.
JPEG– is a standard method of lossy compression of images.
