Understanding the 3Com Web Interface 31
Figure 9 Web Interface Components
The following table lists the user interface components with their
corresponding numbers:
This section provides the following additional information:
■ Device Representation — Provides an explanation of the user
interface buttons, including both management buttons and task
icons.
■ Using the Web Interface Management Buttons — Provides
instructions for adding, modifying, and deleting configuration
parameters.
Table 6 Interface Components
View Description
1 Tree View Tree View provides easy navigation through the configurable
device features. The main branches expand to display the
sub-features.
2 Tab View The Tab Area enables navigation through the different device
features. Click the tabs to view all the components under a
specific feature.
3 Web Interface
Information
Provides access to online help, and contains information about
the Web Interface.
