6
CONFIGURING PORTS
This section contains information for configuring Port Settings, and
includes the following sections:
■ Viewing Port Settings
■ Defining Port Settings
■ Viewing Port Details
Viewing Port
Settings
The Port Administration Summary Page permits the network manager to
view the current port and LAG setting configuration. The Port
Administration Summary Page also displays to which LAGs the port
belongs. When configuring the port speed and port Duplex mode, please
note the following:
■ Setting the port speed to 10/100/1000 and the Duplex mode to Half =
admin speed is = 10/100/1000 half and no advertisement.
■ Setting the port speed to 10/100/1000 and the Duplex mode to Full =
admin speed is = 10/100/1000 full and no advertisement.
■ Setting the port speed to 10/100/1000 and the Duplex mode to Auto
= admin speed is = Admin Advertisement = 10/100/1000 full and half.
■ Setting the port speed to Auto and Duplex mode to Half = Admin
Advertisement = 10+100+1000 half.
■ Setting the port speed to Auto and Duplex mode to Full = Auto -
Admin Advertisement = 10+100+1000 and Full.
■ Setting the port speed to 10/100/1000 and the Duplex mode to Auto
= Admin Advertisement = 10/100/1000 Full+Half.
