DUA1640-5AAA02
C-2
A
PPENDIX
C: S
ERIAL
W
EB
U
TILITY
4
In the
Run
dialog box, type
drive
:\Win95\Drivers\Slip\SETUP
(where
drive
is the letter of your CD-ROM drive) and click
OK
.
The installation program starts and checks your system configuration;
enter any information that’s requested.
If the setup program cannot find specific files on your management
station, it asks you to insert you Windows ‘95 CD-ROM. If it still cannot
find the files, you must obtain them directly from Microsoft. Contact
Microsoft for more information.
5
When the installation program has ensured all the relevant files are
installed, it asks you to select the COM port. This is the serial port on
your management station that you are going to use when connecting
to the hub’s console port.
If you click
Advanced
, the Advanced Configuration Parameters dialog
box is displayed, showing all of the settings the serial web utility will
use when it is run. These default settings are already correct for
connection to the hub so you should not need to change them.
The fields are:
Connection name
Allows you to enter a name for the connection.
Modem name
Allows you to enter a name for the modem connection.
PC SLIP Address
The SLIP address that is to be allocated to the
management station. The default address is ‘192.168.101.2’.
Device URL
The URL that the serial web utility uses to access the hub,
which includes the hub’s SLIP address. For example, the default SLIP
address for the hub is ‘192.168.101.1’ so the URL is:
http://192.168.101.1/
Flow Control
None
/ XON/XOFF / Hardware RTS/CTS
Allows you to specify the flow control that the management station is
to use.
Data bits
,
Stop bits
and
Parity
are all fixed.
Speed
1200 / 2400 / 4800 / 9600 / 19200
Allows you to specify the baud rate that the management station is to
use.
You also have the option of changing the
PC SLIP Address
,
Device URL
,
Flow Control
and
Speed
after the installation is complete.
