DUA1640-5AAA02
Workgroups 1-13
Your workgroups are easy to change. Table 1-2 shows several changes
to the example, and the simple actions needed to implement the
changes:
Figure 1-11
shows the workgroups after the changes have been made.
Figure 1-11
Workgroup Example After Changes
Port switching is independent of the physical connections, so it can be
made quickly and easily, through either local or remote management.
Table 1-2
Changes to the Workgroups
Change to workgroups Hub affected
Action to implement
change
A, B and C become part of
Development (cascaded segment 1)
Top Reconnect segment 1
to cascaded segment 1
R, S and T become part of Marketing
(cascaded segment 3)
Bottom Switch ports for R, S
and T to segment 3
U and V are new users on the bottom
hub and become part of Accounts
Bottom Switch new ports for
U and V to segment 2
To Next Page
