7.1. Measurement Condition
The Analyser provides one Standard Mode and three User Modes with pre set measurement conditions.
List of Measurement Conditions
* When measurement is started and it passes one hour, maximum
temperature is automatically regulated to 160°C for safety.
Drying Rate: Change of moisture content per unit of time.
Example of standard mode
Unit Chart:
Display Data Formula Unit
Moisture content is based on W. *
1
(W - D) / W x 100 % MOIST/W
Moisture content (Atro) is based on D. *
2
(W - D) / D x 100 % MOIST/D
Solid D / W x 100 % RATIO D/W
Ratio *2 W / D x 100 % RATIO W/D
Gram value G
W: Wet sample mass D: Dried sample mass
*
1
: Factory settings
*
2
: When result reaches to 999%, measurement will be terminated.
Storage of Measurement Condition
The analyser can store and recall measurement program that consists of mode, drying temperature,
complete condition, unit and decimal point.
Maximum number MX-50 20 sets (Program number: PROG 1 to 20)
MF-50 10 sets (Program number: PROG 1 to 10)
This function is operated by the program number (PROG), and can store and recall individual settings
already stored.
Measurement conditions of all program numbers are pre-set to that of the Standard Mode at the factory.
Selection of Measurement Method
7
Mode and Display
Measurement Conditions
ACCURACY Sample Mass Analysing Process
Drying Temperature
Standard Mode
HI
Measurement condition is automatically selected by
5td
MID.
ACCURACY. When Drying Rate becomes less than preset
LO
termination value, measurement is completed automatically.
Automatic
When Drying Rate becomes less
50°C to 200°C*
Mode
than preset value, measurement
U-A is completed automatically.
User
Timer Mode
Arbitrary value
Sample is dried for a preset time.
Setting interval is
Mode U-t 0.1g to 50g 1 min. to 480 min. 1°C
Manual Measurement is completed by
Mode the STOP key. Arbitrary time.
U-ñ Max. 480 min.
