MIN SETPT DIFF
Minimum setpoint differential between the
cooling and heating space temperature
setpoints. Used for both the occupied and
unoccupied modes of operation. Default
setpoint differential is 2°F and range is 1-
15°F.
DEADBAND
Space temperature setpoint deadband.
Default setpoint deadband is 2°F and range
is 2-15°F.
SAT COOL SETPT
Cooling supply air temperature setpoint.
Default setpoint is 55°F and range is 50-
70°F.
SAT HEAT SETPT
Heating supply air temperature setpoint.
Default setpoint is 120°F and range is 75-
200°F.
CO2 SETPT (PPM)
Space CO
2
override setpoint. Default
setpoint is 1100 ppm and range is 500-1800
ppm.
DEHUM SETPT
Occupied space relative humidity setpoint.
Default setpoint is 50% RH and range is 20-
85% RH.
DEHUM DEADBAND
Space humidity setpoint deadband. Default
setpoint is 5% RH and range is 5-15% RH.
UNOCC DEHUM SETPT
Unoccupied space humidity setpoint.
Default setpoint is 65% RH and range is 20-
85% RH.
SUCTION (PSI)
Dehumidification suction pressure setpoint.
Default setpoint is 119.4 psi and range is 50-
250 psi.
System
System menu is used for additional startup
configuration.
SYSTEM ENABLE
System Mode of Operation. Default value is
Off.
Auto - Controller will maintain both the
space heating and cooling setpoints with
operation depending on the space
temperature.
Cooling - Controller will maintain only the
space cooling setpoint.
Heating - Controller will maintain only the
space heating setpoint.
Emergency Heating - Controller will
maintain only the space heating setpoint
using only emergency heating.
Off - Turns the controller operation off.
OCC OVRIDE (HRS)
Amount of time a space temperature setpoint
override and occupancy override will last.
Default value is 1 hour and range is 0-12
hours. When set at 0, the override will last
until the next schedule change.
INACTIVITY (SECS)
Amount of time the backlight will stay on
and the current password will stay active
after the last button push. Default value is 60
seconds and range is 5-600 seconds.
DISPLAY BLANKING
Available options are Yes and No. Default
value is No. With Yes selected, display will
turn off at the same time the backlight goes
off. With No selected, display will turn stay
on when the backlight goes off. When any
key is pressed the display and backlight will
turn on.
Trend Viewer
Trend viewer displays the trend logs that
have already been setup. Press Enter when
the trend is highlighted to view details.
