AAON Mini Controller - BACnet Analog Values; Analog Value Definitions

40
BACnet Points List
Table 4 - Analog Values
Object
Read/Write
Description
Default
Min
Max
AV1
R/W
Min Space Temp Setpoint Diff
2°F
1°F
15°F
AV2
R
Active Cooling Setpoint
-
-
-
AV3
R
Active Heating Setpoint
-
-
-
AV4
R/W
Unocc Cooling Setpoint
80°F
55°F
90°F
AV5
R/W
Unocc Heating Setpoint
64°F
55°F
90°F
AV6
R/W
Deadband
2°F
1°F
15°F
AV7
R/W
Occ Min Cooling Setpoint
68°F
55°F
90°F
AV8
R/W
Occ Max Heating Setpoint
72°F
55°F
90°F
AV9
R/W
Cooling Supply Air Setpoint
55°F
50°F
70°F
AV10
R/W
Econ Min OA Damper Pos
10%
0%
95%
AV11
R/W
Econ OA Temp Enable
60°F
50°F
70°F
AV12
R/W
Compressor Stage Delay
3 min
2 min
15 min
AV13
R/W
Fan Shutoff Delay
180 sec
0 sec
600 sec
AV14
R/W
Heat Stage Delay
3 min
3 min
60 min
AV15
R/W
Dehumidification Setpoint
50%
20%
85%
AV16
R/W
Override Timer
1 hour
0 hour
12 hour
AV17
R/W
Compressor OA Temp Lockout
40°F
0°F
50°F
AV18
R/W
Economizer SA Low Limit
40°F
0°F
100°F
AV19
R/W
CO2 Setpoint
1100 ppm
500 ppm
1800 ppm
AV20
R/W
Occ Cooling Setpoint
74°F
55°F
90°F
AV21
R/W
Occ Heating Setpoint
70°F
55°F
90°F
AV22
R
Space Humidity
-
-
-
AV23
R
Outside Air Temp
-
-
-
AV24
R
Supply Air Temp
-
-
-
AV25
R
Configurable Input - AI2
-
-
-
AV26
R
Current Mode Setpoint
-
-
-
AV27
R
UI Setpoint
-
-
-
AV28
R/W
Dehumidification Deadband
5%
5%
15%
AV29*
R/W
Cooling Loop P
2
0.50
10.00
AV30*
R/W
Cooling Loop I
0.1
0.01
1.00
AV31
R/W
Unocc Min Cooling Setpoint
68°F
55°F
90°F
AV32
R/W
Unocc Max Heating Setpoint
72°F
55°F
90°F
AV33
R/W
Minimum Setpoint Differential
2°F
1°F
15°F
AV34
R/W
Minimum Setpoint Limit
2°F
1°F
15°F
AV35*
R/W
Heating Loop P
2
0.50
10.00
AV36*
R/W
Heating Loop I
0.1
0.01
1.00
AV37*
R/W
Economizer Loop P
2
0.50
10.00
AV38*
R/W
Economizer Loop I
0.1
0.01
1.00
AV40
R
UI Display Space Temerature
-
-
-
AV41
R/W
Min Digital Comp Setpoint
50%
20%
80%
AV42
R/W
Max Digital Comp Setpoint
100%
5%>min
100%
AV43
R/W
Cool Supply Fan Min Speed
Setpoint
30%
30%
80%
* Through version R1.2.2.10 these are only accessible through BACnet
