AAON Mini Controller - BACnet Multi-State and Input;Output Values; Multi-State Values; Analog Inputs; Analog Outputs

42
Table 7 - Multi-State Values
Object
Read/Write
Description
Options
MSV1
R/W
Application Main
Standard, Heat Pump
MSV2
R/W
Application Sub
#Heat Stages/#Cool
Stages or
#Comp Stages/#Emer.
Heat Stages
MSV3
R/W
Fan Control
Constant Speed, Variable
Speed Cool, Variable
Speed Cool and Heat
MSV4
R/W
Economizer Damper
None, Fully Modulating
MSV5
R/W
Configurable Input -
AI2
None, Fan Status, CO
2
,
Compressor Suction
Pressure, OA Humidity,
Average Remote Space
Temp, Standalone Space
Temp
MSV6
R/W
Supply Air Temp
Control
None, Supply Air Temp
Cool, Supply Air Temp
Heat and Cool
MSV7
R/W
System Mode
Auto, Heat, Cool, Emer.
Heat, Off
MSV8
R/W
Dehumidification/Ener
gy Recovery
None, Dehumid/Heat
Wheel
MSV13
R/W
BO5 Option
Not Used, Comp 1
Table 8 - Analog Inputs
Object
Read/Write
Description
AI1
R
Space Temp
AI2
R
Configurable Input
AI3
R
Supply Air Temp
AI4
R
Outside Air Temp
AI5
R
Space Humidity
Table 9 - Analog Outputs
Object
Read/Write
Description
AO7
R
Digital Compressor
AO8
R
Variable Speed Fan
AO9
R
Economizer Damper
Table 10 - Relay Outputs
Object
Read/Write
Description
BO1
R
Fan
BO2
R
Compressor 2
BO3
R
Heat 1/Reversing Valve
BO4
R
Heat 2/Emergency Heat 1
BO5
R
Heat 3/Emergency Heat 2/Y2
BO6
R
Dehumidification/Heat Wheel
