AAON Mini Controller - BACnet Analog Values Continued; Analog Value Definitions; BACnet Relay Values; Relay Value Definitions

41
Table 5 - Analog Values Continued
AV44
R/W
Cool Supply Fan Max Speed
Setpoint
100%
50%
100%
AV45
R/W
Dehum Suction PSI Setpoint
119.4 psi
50 psi
250 psi
AV46
R/W
Dehum Fan Speed Setpoint
50%
25%
75%
AV47
R/W
Unocc Dehum Setpoint
65%
20%
85%
AV48
R/W
SAT Low Limit Alarm
40°F
32°F
60°F
AV49
R/W
Heat Supply Fan Min Speed
Setpoint
50%/75%
50%
100%
AV50
R/W
Heat Supply Fan Max Speed
Setpoint
100%
>Min
100%
AV51
R/W
Heating Supply Air Temp Setpoint
120°F
75°F
200°F
AV52
R/W
Heating OAT High Limit
70°F
50°F
150°F
AV53
R/W
SAT High Limit Alarm
200°F
120°F
250°F
AV54
-
Not Used
-
-
-
AV55
R/W
Occ Min Heating Setpoint
65°F
53°F
90°F
AV56
R/W
Occ Max Cooling Setpoint
78°F
55°F
92°F
AV57
R/W
OAT Low Limit
150°F
110°F
160°F
AV58
R/W
OAT High Limit
-40°F
-50°F
40°F
AV59
-
Not Used
-
-
-
AV60
-
Not Used
-
-
-
Table 6 - Relay Values
Object
Read/Write
Description
BV1
R
Occupancy Mode
BV2
R
Setpoint Override Mode
BV3
R
Economizer Mode
BV4
R
Economizer SA Temp Low
Limit
BV5
R
Fan Alarm
BV6
R
Fan Need
BV7
R
Heating/Cooling Mode
BV8
R
Compressor Lockout
BV12
R/W
Occ Fan Auto/On
BV13
R/W
Unocc Fan Auto/On
BV14
R/W
°F/°C
BV15
R/W
Reversing Valve Polarity
BV16
R
Fan Status
BV17
R
Backlight Control
BV18
R
U/I Fan Icon
BV21
R
Dehum Mode Active
BV24
R
Occ Sensor Override Enable
BV31
R/W
Dehum Priority
BV36
R
Allow Econ Cooling
BV37
R
Comp 1 On/Off
BV38
R
OAT Sensor Installed
BV39
R
SAT Sensor Installed
BV40
R
Econ with Enthalpy
