Advanced Menu Configuration
(Advanced) Application
Application menu is used for application
configuration.
DEGREE SCALE
°F or °C
APP
Controller application
Standard - Air conditioner application
Heat Pump - Heat pump application
Not Configured - Default value
OPT
Number of heating and cooling stages. Air
conditioners are available with 1 or 2 stages
of cooling and 1, 2 or 3 stages of heating.
Heat pumps are available with 1 or 2
compressor stages, 0, 1 or 2 stages of
emergency heat.
SAT CONTROL
Available options are No SAT Control, SAT
Cooling Only Control and SAT Heating &
Cooling Control. Use for single zone VAV
applications with supply air temperature
cooling capacity control or supply air
temperature cooling and heating capacity
control.
ADDITIONAL SETUP
HEAT - DELAY (MINS)
Stage delay between auxiliary heating
stages. Default value is 3 minutes and range
is 3-60 minutes.
HEAT1 MIN OFF (SECS)
Heating minimum off time. Default is 120
seconds and range is 120-600 seconds.
HEAT1 MIN ON (SECS)
Heating minimum on time. Default is 120
seconds and range is 120-600 seconds.
DAMPER - ECON
Available economizer options are None or
Modulating.
DAMPER - ENTHALPY
Available economizer options are Enable or
Disable.
DAMPER - MIN POSITION (%)
Minimum economizer damper position.
Default value is 10% and range is 0-95%.
DAMPER - CNTRL (0-100%)
Available options are 0-10 VDC, 10-0 VDC,
2-10 VDC or 10-2 VDC. Default value is 0-
10 VDC.
DAMPER - ECON ENBLE TEMP
Economizer enable outside air temperature
setpoint. Default setpoint is 60°F and range
is 50-70°F.
DAMPER - LOW LIMIT
Economizer supply air temperature low limit
which returns the economizer to the
minimum position. Default value is 45°F
and range is 0-100°F.
FAN - SPEEDS
Available options are Constant Spd C & H,
Variable Spd Cool Only, or Variable Spd
Cool and Heat.
Constant Spd C & H - Constant volume
application.
Variable Spd Cool Only - Single zone VAV
application with single zone VAV cooling
and constant volume heating.
Variable Spd C & H - Single zone VAV
application with single VAV cooling and
single zone VAV heating.
FAN - OFF DELAY (SECS)
Amount of time the fan will continue to run
after heating and cooling is deactivated with
Auto fan operation. Default value is 180
seconds and range is 0-600 seconds.
FAN - COOL MAX SPEED
Maximum cooling speed of a variable speed
fan. Default is 100%, range is 50-100% and
value must be greater than the minimum
cooling speed.
