AAON RN Series - Feature 6: Filters

21
RN Series Feature String Nomenclature
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
– 0 2 5 – 3 – 0 –
B
B
0 2 – 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
– 0 0 – 0 0
B
0 0 0 0 0
B
GEN
5C: SUPPLY AIR BLOWER MOTOR
C = 1 hp - 1760 rpm
D = 2 hp - 1760 rpm
E = 3 hp - 1760 rpm
F = 5 hp - 1760 rpm
G = 7.5 hp - 1760 rpm
H = 10 hp - 1760 rpm
L = 15 hp - 1760 rpm
M = 20 hp - 1760 rpm
N = 1 hp - 1170 rpm
P = 2 hp - 1170 rpm
Q = 3 hp - 1170 rpm
R = 5 hp - 1170 rpm
S = 7.5 hp - 1170 rpm
T = 10 hp - 1170 rpm
U = 15 hp - 1170 rpm
V = 20 hp - 1170 rpm
W = 25 hp - 1170 rpm
Y = 30 hp - 1170 rpm
3 = 25 hp - 1760 rpm
4 = 30 hp - 1760 rpm
5 = 40 hp - 1760 rpm
6 = 50 hp - 1760 rpm
Feature 6: FILTERS
6A: PRE FILTER
0 = Standard - None
A = 2” Pleated - MERV 8
B = Metal Mesh Outside Air Filter
C = Lint Screen Filter
D = Exhaust Air ERW Filter
E = Options A + B
F = Options A + D
G = Options B + D
H = Options A + B + D
6B: UNIT FILTER
0 = 2” Pleated - MERV 8
B = 4” Pleated - MERV 8
C = 2” Permanent Filter + Replaceable Media
F = 4” Pleated - MERV 11
G = 4” Pleated - MERV 13
H = 4” Pleated - MERV 14
6C: FILTER OPTIONS
0 = Standard
A = Clogged Filter Switch
B = Magnehelic Gauge
C = Options A + B
Feature 7: REFRIGERATION
CONTROL
0 = Standard
A = 5 Min. Time Delay Relay - Comp. Off
B = 20 Sec. Time Delay Relay - Comp. Staging
D = Adjustable Lockout
E = Freeze Stats - Each Circuit
F = Options A + B
H = Options A + D
J = Options A + E
L = Options B + D
M = Options B + E
N = Adjustable Fan Cycling with Adjustable
Compressor Lockout
Q = Options D + E
S = Options A + B + D
T = Options A + B + E
U = Options A + N
W = Options A + D + E
Y = Options B + N
1 = Options B + D + E
2 = Options N + E
3 = Options A + B + N
5 = Options A + B + D + E
6 = Options A + N+ E
7 = Options B + N + E
8 = Options A + B + N + E
