AAON RN Series User Manual

22
RN Series Feature String Nomenclature
:
SIZE
VLT
CONFIG
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
15
16
17
18
19
20
21
22
23
R
N
– 0 2 5 – 3 – 0 –
B
B
0 2 – 3 8 4 :
A
0 0 0 –
D
0
B
–
D
E
H
– 0
B
A
– 0
D
0 0 0 0
L
– 0 0 – 0 0
B
0 0 0 0 0
B
GEN
Model Options
Unit Feature Options
Feature 8: REFRIGERATION OPTIONS
0 = Standard
A = Hot Gas Bypass Lead Stage or Hot Gas Bypass
Lag Stage with Lead Variable Capacity
Compressor
B = Hot Gas Bypass Lead and Lag Stages
D = Modulating Hot Gas Reheat
E = 0°F Low Ambient Lead Stage
H = Options A + D
J = Options B + D
K = Options A + E
L = Options B + E
N = Polymer E-Coated Modulating Hot Gas Reheat
R = Options A + N
S = Options B + N
T = Parallel Modulating Hot Gas Reheat
Microchannel Coil - Lag Circuit
U = Options A + T
V = Options B + T
W = Polymer E-Coated Parallel Modulating Hot Gas
Reheat Microchannel Coil - Lag Circuit
Y = Options A + W
Z = Options B + W
1 = All Circuit Parallel Modulating Hot Gas Reheat
Microchannel Coil
2 = Options A + 1
3 = Options B + 1
4 = Polymer E-Coated All Circuit Parallel
Modulating Hot Gas Reheat Microchannel Coil
5 = Options A + 4
6 = Options B + 4
Feature 9: REFRIGERATION
ACCESSORIES
0 = Standard
A = Sight Glass
B = Compressor Isolation Valves
C = Options A + B
D = ECM Condenser Fan - Multiple Speed
E = ECM Condenser Fan - Head Pressure Control
F = VFD Controlled Condenser Fans - Variable
Speed
G = Options A + D
H = Options B + D
J = Options A + B + D
K = Options A + E
L = Options B + E
M = Options A + B + E
N = Options A + F
P = Options B + F
Q = Options C + F
R = Low Sound Condenser Fan - Head Pressure
Control
S = Options R + A
T = Options R + B
U = Options R + A + B

AAON RN Series Specifications

General

Category	Heat Pump
HSPF	Up to 10.0
Refrigerant	R-410A
Compressor Type	Scroll
Efficiency	High
Series	RN
Voltage Options	208-230/460V
Unit Weight	Varies with model
Dimensions	Varies with model
