RSMV Technical Guide
INPUTS AND OUTPUTS
RSMV Module Inputs/Outputs Map
Inputs/Outputs Map
See Table 2, below for the RSMV inputs and outputs.
Table 2: RSMV Inputs and Outputs
RSMV Inputs/Outputs
Analog Inputs
1 Suction Pressure Sensor (SP)
2 Head Pressure Sensor (HP)
3 Coil (Suction Line) Temperature Sensor 1 (TEMP1)
4 Coil (Suction Line) Temperature Sensor 2 (TEMP2)
Binary Inputs
1 Compressor Status 1 (BIN1)
2 Compressor Status 2 (BIN2)
Analog Outputs (0-10 VDC)
1 Modulating Compressor (AOUT1)
2 Condenser Fan Signal (AOUT2)
Stepper Motor Outputs
1 Expansion Valve 1 (EXV-1)
2 Expansion Valve 2 (EXV-2)
Binary Outputs (24 VAC)
1 Compressor 1 Enable Relay (R1)
2 Compressor 2 Enable Relay (R2)
3 Condenser Enable Relay (R3)
