RSMV Technical Guide
Figure 10: Prism 2 RSMV Conguration Screen
General
Refer to Figure 10, below in setting RSMV conguration options.
The following features are not compatible with the RSMV:
• RSMV-Q Tonnage Selection
• Two Step Timing
Compressor Congurations
Make selection from the drop-down menu for Module A, see
Figure 11.
Note: Danfoss compressors are not compatible with the
RSMV.
For the remaining modules, select the appropriate compressor.
Select “No Compressor Congured” when there are no additional
compressors.
APPENDIX B: PRISM 2 SYSTEM CONFIGURATION
System Conguration
Figure 11: RSMV Module A Compressor Type
