AAON RSMV ASM01686 - Diagnostic Screens

20
RSMV Technical Guide
RSMV LCD SCREENS
Diagnostic Screens
Diagnostic Screens
Refer to the following map when navigating through the Diagnostic
Screens. From the DIAGNSTC Screen, press <ENTER> to scroll
through the screens.
DIAGNSTC
WDOG CNT
#
WATCH DOG TIMER
Displays the number of times the board has been reset due to
watchdog timer overow.
PWER CNT
#
POWER LOSS COUNT
Displays the number of times the board has been
reset due to power loss.
EEPROM:
HOLD
DOWN
TO
LOAD
DEFAULTS
SP-A VLT
X.XX
SUCTION PRESSURE SENSOR VOLTAGE
Displays the current voltage of the Suction Pressure Sensor.
HP-A VLT
X.XX
HEAD PRESSURE SENSOR VOLTAGE
Displays the current voltage of the Head Pressure Sensor.
BIN1 - BIN4
ON/OFF
BINARY INPUTS #1 - #4
Displays the current status of each Binary Input.
TMP1 VLT
X.XX
COIL TEMPERATURE SENSOR 1 VOLTAGE
Displays the current voltage of the 1st Coil Temperature Sensor.
TMP2 VLT
X.XX
COIL TEMPERATURE SENSOR 2 VOLTAGE
Displays the current voltage of the 2nd Coil Temperature
Sensor.
TMP5 VLT
X.XX
TEMPERATURE SENSOR 5 VOLTAGE (NOT USED)
