RSMV Technical Guide
RSMV LCD SCREENS
System Status Screens
System Status Screens
Refer to the following map when navigating through the System
Status Screens. From the SYSTEM STATUS Screen, press
<ENTER> to scroll through the screens.
#OF EXVs
#
# OF EXPANSION VALVES
COMP A1=
MOD OR FIXED
COMPRESSOR A1 STATUS
#OF COND
1 or 0
# OF CONDENSERS
SYSTEM
STATUS
MODE
SYSTEM MODE
Possible choices are
OFF, COOL, HEAT, DEHUMID, FORCE
COMP A1-D1
OFF/
MODULATING %
COMPRESSOR A1, B1, C1, D1
(based on board address)
OFF / MOD POSITION
OFF: Compressor is o.
MODULATING PERCENTAGE: 0-100%
COMP A2-D2
ON/OFF
COMPRESSOR A2, B2, C2, D2
(based on board address)
ON, OFF, FORCE
ON: Compressor is on. OFF: Compressor is o.
COND FAN
NOT USED/OFF/
MODULATING %
CONDENSER FAN
NOT USED, OFF, MOD POSITION
OFF: Condenser is o.
MODULATING PERCENTAGE: 0-100%
EXV A1-D1
0%
EXV A1, B1, C1, D1
(based on board address)
EXV VALVE POSITION
0 to 100 percent
EXV A2-D2
0%
EXV A2, B2, C2, D2
(based on board address)
EXV VALVE POSITION
0 to 100 percent
To Next Page
