RSMZ LCD SCREENS
System Status Screens
System Status Screens
Refer to the following map when navigating through the System
Status Screens. From the SYSTEM STATUS Screen, press
<ENTER> to scroll through the screens.
STATUS
MENU
MODE
SYSTEM MODE
MIN RUN, OFF, COOLING, HEATING, DEHUM, or FORCED
STAGE
#
NUMBER OF STAGES
COMP%
0%
COMPRESSOR STATUS
COND%
0%
CONDENSER STATUS
STAGE UP
0
STAGE UP STATUS
C1 MIN RUN
0
COMPRESSOR 1 MINIMUM RUN TIME
C2 MIN RUN
0
COMPRESSOR 2 RUN TIME
C1 MIN OFF
0
COMPRESSOR 1 MINIMUM OFF TIME
C2 MIN OFF
0
COMPRESSOR 2 MINIMUM OFF TIME
To Next Page
