RSMZ Technical Guide
RSMZ LCD SCREENS
Sensor and Setpoint Status Screens
Sensor Status Screens
Refer to the following map when navigating through the Sensor
Status Screens. From the SENSOR MENU Screen, press
<ENTER> to scroll through the screens.
SENSOR
MENU
SUPPLY
XX.X°F
SUPPLY AIR TEMPERATURE READING FROM INPUT
SATURATN
XX.X°F
SATURATION TEMPERATURE READING FROM INPUT
DISCHRGE
XXX PSIG
DISCHARGE PRESSURE READING FROM INPUT
DISCHRGE
XX.X°F
DISCHARGE TEMPERATURE READING FROM INPUT
SUCTION
XXX PSIG
SUCTION PRESSURE READING FROM INPUT
SUPRHEAT
XX.X°F
SUPERHEAT READING FROM TEMPERATURE
SENSOR INPUT
Setpoint Status Screens
Refer to the following map when navigating through the Setpoint
Status Screens. From the SETPOINT STATUS Screen, press
<ENTER> to scroll through the screens.
SETPOINT
STATUS
SUPPLYSP
XX.X°F
SUPPLY TEMPERATURE SETPOINT
EVAPCLSP
XX.X°F
EVAPORATOR COIL TEMPERATURE SETPOINT
DSCHG SP
XXX PSI
DISCHARGE PRESSURE SETPOINT
SHEAT SP
XX.X°F
SUPERHEAT SETPOINT
