Technical Data
199
The following table provides an overview of the configuration limits for the
OpenCom 510. These limits result from the combination of different interface
cards.
OpenCom 510: system configuration limits (single 19" frame)
Interface card
(module)
maximal
insertable
Maximum num-
ber of interfaces
Note
MC+1-3 1 2 1 x Ethernet
(10/100 Mbits/s), 1 x V.24
MT+S2M1-1 4 4 x S
2M
–
MX+S01-8 12 96 x S
0
(for internal or external
use)
MS+UPN1-8 11 88 x U
pn
– with a single 19" frame (a
total of 12 slots) one slot is
required for the outside
line
– with a cascaded system
(two 19" frames) 12 inter-
face cards of this type can
be inserted in the 19"
frame of the slave system
MS+UPN2-8 11 88 x U
pn
–U
pn
interfaces are
DECT-capable
– with a single 19" frame (a
total of 12 slots) one slot is
required for the outside
line
– with a cascaded system
(two 19" frames) these in-
terface cards can only be
inserted in the 19" frame of
the master system
