Modules MS+UPN2-8
81
7.8 MS+UPN2-8
Field of Application
The MS+UPN2-8 interface card provides eight U
pn
interfaces for connecting
system terminals and DECT base stations.
The MS+UPN2-8 interface card can be installed in any of the slots (1 to 12) of the
OpenCom 510 (see Slots starting on page 27).
Technical Information
■ The MS+UPN2-8 interface card can also be installed in a slave system.
■ A maximum of 48 RFPs (Radio Fixed Parts, DECT base stations) can be con-
nected to the entire system.
■ In order to connect RFPs, U
pn
ports 1+2, 3+4, 5+6 or 7+8 can be combined by
setting the DIP switches on the card accordingly.
For further information, refer to Upn Ports starting on page 44.
■ The MS+UPN2-8 interface card runs on software acquired from the system.
After the card has been installed it will automatically load the required
software.
Pin Assignment
For information on the U
pn
interface pin assignment, refer to Upn Ports starting on
page 44.
Indicators
There are four LEDs on the front of the MS+UPN2-8 interface card.
