Aastra OpenCom 510 - Mps+1-Ac

Modules MPS+1-AC
65
7.3 MPS+1-AC
Field of Application
The MPS+1-AC power supply unit supplies power to the first six slots (1 to 6) of the
OpenCom 510. It converts the (220 V/110 V) AC input voltage into DC voltage
+3.3 V and
–42 V.
If the remaining slots (7 to 12) are to be used, a second MPS+1-AC power supply
unit will need to be installed.
MPS+1-AC: Front view
Technical Data
The following data refer to the supply of power to the first six slots.
MPS+1-AC
