7.7 MS+UPN1-8
Field of Application
The MS+UPN1-8 interface card provides eight U
pn
interfaces for connecting
system terminals; however, it is not possible to connect DECT base stations.
The MS+UPN1-8 interface card can be installed in any of the slots (1 to 12) of the
OpenCom 510 (see Slots starting on page 27).
Technical Information
■ The MS+UPN1-8 interface card can also be installed in a slave system.
■ No settings need to be made on the MS+UPN1-8 interface card.
■ The MS+UPN1-8 interface card runs on software acquired from the system.
After the card has been installed it will automatically load the required
software.
Pin Assignment
Indicators
There are four LEDs on the front of the MS+UPN1-8 interface card.
RJ45 Connector Pin Assignment for the MS+UPN1-8 Interface
Pin Number Assignment
1Not used
2Not used
3Not used
4U
pn
a
5U
pn
b
6Not used
7Not used
8Not used
