Basic operation 25
Basic operation
What this chapter contains
The chapter describes the basic operations and components of the user interface. It
also lists the common user tasks and provides instructions to complete the task.
User interface overview
The user interface has the following main components:
Component Description
Home view Used to monitor signals. See Home view (page 22).
Menu Access to most functions of the control panel. See the detailed
description in chapter Functions in the main Menu (page 31).
Options Used to set a reference, change the motor direction, select the drive,
edit Home view pages, and see the fault and warning status. See the
detailed description in chapter Functions in the Options menu
(page 27).
Help Provides information on the current view or menu or on possible
problems associated with it. See Help (page 22).
Faults and warnings View faults and warnings when the drive or control panel experiences
an error. See Fault tracing (page 57).
