Functions in the main Menu 45
Primary settings
The Primary settings menu has the following sub-menus.
Note: The contents displayed may vary based on the drive/device to which the panel
is connected. The menu shown is only an example.
Show in lists Show or hide the numeric IDs of:
• parameters and groups
• option list items
•bits
• devices in Options
→ Select drive.
Pass code Enter pass codes into this parameter to activate further access levels (for
example additional parameters).
Sub-menu Function
Macro Set up drive control and reference source by selecting from a set of
predefined wiring configurations.
Drive Adjust drive related settings, such as control location, run permissions,
ramps, limits, constants speeds, flying starts references.
Motor Adjust motor-related settings, such as control mode, nominal values, ID
run or thermal protection. Note that the settings that are visible depend
on other selections, for example vector or scalar control mode, used
motor type or selected start mode.
Loop controller Set up loop controller settings and actual values. Loop controller is only
used in remote control.
Pump and fan
control
Controls one motor connected to the drive and up to 3 auxiliary motors.
Communication Use the drive with a fieldbus.
Start, stop,
reference
Set up start/stop commands, reference, and related features, such as
constant speeds or run permissions.
Ramps Set up acceleration and deceleration settings.
Limits Set the allowed operating range. This function is intended to protect the
motor, connected hardware and mechanics. The drive stays within
these limits, no matter what reference value it gets.
Sub-menu Function
