Control panel navigation
Use the arrow keys and softkeys for navigation. Follow the choices on the screen.
Energy efficiency
Parameters
Assistants
Event log
History graphs
Backups
System info
Settings
Reference
Direction change
Select drive
Edit Home view
Active faults
Active warnings
Menu
Options
Note: The menu shown is an example only. The Menu varies based on the drive/device to
which the panel is connected.
￭ Navigation memory
The Assistant control panel has a navigation memory that allows you to backtrack your
steps through the user interface with the arrow keys and . The path you have last
accessed remains in the memory for 10 minutes.
•
The left arrow key ( ) moves you backwards in the menu structure.
If you press repeatedly, you return back to the Home view.
•
The right arrow key ( ) moves you forward in the menu structure.
If you press repeatedly, you move forward along the path in the menu structure you
had previously accessed.
28 Basic operation
