Name Value Internal
Value
Internal
Value ,
Type
Default Min. Max. EDS Slot
Index
Module ID Internal 6105 WORD 6105
0x17D9
0 65535 xx01
Ignore
module
No
Yes
0
1
BYTE No (0x00)
Parameter
length
1
)
Internal 1 - CPU BYTE 0 0 255
xx02
2
)
1
) the module has no additional user-configurable parameters
2
) Value is hexadecimal: HighByte is slot (xx: 0...7), LowByte is index (1...n)
GSD file:
Ext_User_Prm_Data_Len =
Ext_User_Prm_Data_Const(0) =
0x03
0xDA, 0x17, 0x00;
6.2.1.6 Diagnosis
Class Comp Dev Mod Ch Err PS501
PLC
Browser
<− Display in
Class Interface Device Module Channel Error
Identifier
Error message Remedy
1
)
2
)
3
)
4
)
Module error
3 14 1...10 31 31 19 Checksum error in the
I/O module
Replace
I/O module
11 / 12 ADR 1...10
3 14 1...10 31 31 43 Internal error in the
module
Replace
I/O module
11 / 12 ADR 1...10
3 14 1...10 31 31 9 Overflow diagnosis
buffer
Restart
11 / 12 ADR 1...10
3 14 1...10 31 31 26 Parameter error Check
master
11 / 12 ADR 1...10
Remarks:
1
)
In AC500 the following interface identifier applies:
14 = I/O bus, 11 = COM1 (e.g. CS31 bus), 12 = COM2.
The PNIO diagnosis block does not contain this identifier.
2
)
With "Device" the following allocation applies:
31 = module itself,
1...10 = decentralized communication interface module 1...10,
ADR = hardware address (e. g. of the DC551-CS31)
