Fig. 8: Insertion: PM56xx
1 MC5102 micro memory card
2 Micro memory card adapter
Slot for memory card
NOTICE!
Removal of the micro memory card
Do not remove the micro memory card during access. Remove only when the
RUN LED does not blink. Otherwise the micro memory card and/or files on it
might get corrupted and/or normal PLC operation might be disturbed.
AC500-eCo V3
To remove the micro memory card, push on the micro memory card until it moves forward. By
this, the micro memory card is unlocked and can be removed.
Remove the
micro memory
card
Device specifications
Accessories > MC5102 - micro memory card with micro memory card adapter
