Range 0 … 20 mA 4 … 20 mA Digital value (dec) Digital value (hex)
Overflow
:
> 23.519
:
> 22.81
32767*
:
32512*
7FFF*
:
7F00*
Overrange
23.519
:
20.000723
22.81
:
20.000578
32511
:
27649
7EFF
:
6C01
Nominal
range
20
:
0
20
:
16
:
4
27648
:
20736
:
0
6C00
:
5100
:
0000
Underrange
–0.000723
:
–1.481
3.999421
:
1.185
0 … 20 mA 4 … 20 mA 0 … 20 mA 4 … 20 mA
–1
:
–2048
–1
:
–4864
FFFF
:
F800
FFFF
:
ED00
Underflow
< –1.481
< 1.185
0 … 20 mA 4 … 20 mA 0 … 20 mA 4 … 20 mA
–2049*
:
–32768*
–4865*
:
–32678*
F7FF*
:
8000*
ECFF*
:
8000*
* In these cases, the analog channels are passivated and “0” process values are delivered to the Safety
CPU.
3.5.3 Mounting, dimensions and electrical connection
The input modules can be plugged only on spring-type TU582-S I/O Terminal Unit. The unique mechanical
coding on I/O Terminal Units prevents a potential mistake of placing the Non-safety I/O module on Safety I/O
Terminal Unit and the other way around.
Installation and maintenance have to be performed according to the technical rules, codes and relevant
standards, e.g. EN 60204 part 1, by skilled electricians only.
AC500-S Safety Modules
AI581-S analog safety input module > Mounting, dimensions and electrical connection
30.03.2017 AC500-S 139
