Name Data Type Initial Value Description, Parameter Values
ERR BOOL FALSE Error occurred (data segment could not be read)
This output always has to be considered together
with output DONE. The following applies if an
error occurred: DONE = TRUE and ERR = TRUE.
Output ERNO indicates the error number.
ERNO WORD 16#0000
Error number (
Ä
[4] for more details).
Output ERNO indicates an error number. This
output always has to be considered together with
the outputs DONE and ERR.
The SF_FLASH_READ operation may take quite
a long time since the PLC user program is pro-
cessed with priority. Output ERNO then indicates
that the function block has started the execution
(0x0FFF = BUSY).
During this phase, the outputs ERR and DONE
are set to FALSE.
The structure of one of the Flash memory segments with user data is presented below.
Byte: 1 | 2 3 | 4 5 | 6 … 29 | 30 31 | 32 33 …
36
37 38
Byte
offset
Block
no.
Word 1 Word 2 Word 3 … Word
15
Word
16
CRC Written
identi-
fier
Align-
ment
0 0
38 1
76 2
… …
65436 1722
65474 1723
Call in ST
READ_FLASH(EN := EN_FLASH_READ,
NB := NB_FLASH_READ,
SEG := SEG_FLASH_READ,
BNR := BNR_FLASH_READ,
SM := SM_FLASH_READ,
DONE => DONE_FLASH_READ,
