DiagCode State Name State Description and Output Setting
8001 Init Function block was activated and initiated.
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = FALSE
Error = FALSE
8003 Wait for Reset Door is closed and locked, now waiting for operator reset
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = FALSE
Error = FALSE
8011 Wait for Oper-
ator
Waiting for operator to either unlock request or reset.
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = FALSE
Error = FALSE
8012 Guard Open
and Unlocked
Lock is released and guard is open.
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = TRUE
Error = FALSE
8013 Guard Closed
but Unlocked
Lock is released but guard is closed.
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = TRUE
Error = FALSE
8014 Safety Return Return of S_SafetyActive signal, now waiting for operator acknowledge.
Ready = TRUE
S_GuardLocked = FALSE
S_UnlockGuard = FALSE
Error = FALSE
Configuration and programming
AC500-S Libraries > SafetyBlocks_PLCopen_AC500_v22.lib
