DiagCode State Name State Description and Output Setting
C004 Reset Error 4 Static Reset condition detected in state C020.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C005 Reset Error 5 Static Reset condition detected in state 8006.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C006 Reset Error 6 Static Reset condition detected in state C000.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = FALSE
Error = TRUE
C007 Reset Error 7 Static Reset condition detected in state 8013.
Ready = TRUE
S_OSSD_Out = FALSE
S_TestOut = TRUE
TestPossible = FALSE
TestExecuted = TRUE
Error = TRUE
