ABB ACH550-01 - Frame Size

Preparing for installation 17
ACH550-01 User's Manual
Frame size
Type
ACH550-01-
I
2N
A
P
N
kW
Frame size
Three-phase supply voltage, 220…240 V
04A6-2 4.6 0.75 R1
06A6-2 6.6 1.1 R1
07A5-2 7.5 1.5 R1
012A-2 11.8 2.2 R1
017A-2 16.7 4.0 R1
024A-2 24.2 5.5 R2
031A-2 30.8 7.5 R2
046A-2 46 11 R3
059A-2 59 15 R3
075A-2 75 18.5 R4
088A-2 88 22 R4
114A-2 114 30 R4
143A-2 143 37 R6
178A-2 178 45 R6
221A-2 221 55 R6
248A-2 248 75 R6
Three-phase supply voltage, 380…480 V
02A4-4 2.4 0.75 R1
03A3-4 3.3 1.1 R1
04A1-4 4.1 1.5 R1
05A4-4 5.4 2.2 R1
06A9-4 6.9 3.0 R1
08A8-4 8.8 4.0 R1
012A-4 11.9 5.5 R1
015A-4 15.4 7.5 R2
023A-4 23 11 R2
031A-4 31 15 R3
038A-4 38 18.5 R3
045A-4 45 22 R3
