Start-up and control panel 79
ACH550-01 User's Manual
Constant Speeds • Prompts for the use of constant speeds
• Prompts for constant speed values
PID control • Prompts for PID settings
• Prompts for the source of the process
reference
• Prompts for reference limits
• Prompts for the source, limits and units of the
process actual value
• Defines the use of Sleep function
PID Flow • Prompts for the use of flow calculation.
• Prompts for units.
• Prompts for maximum flow.
• Prompts for transmitter signals.
Low Noise Set-up • Prompts for the switching frequency
• Prompts for the definition of Flux optimization
• Prompts for the use of Critical speeds
Panel Display • Prompts for display variable and unit settings
Timed Functions • Prompts for the use of Timed functions
Outputs • Prompts for the signals indicated through the
relay outputs
• Prompts for the signals indicated through the
analogue outputs AO1 and AO2. Sets the
minimum, maximum, scaling and inversion
values.
Serial
Communication
• Prompts for communication settings.
• Prompts for control access settings.
Task name Description
