Preparing for installation 27
ACH550-01 User's Manual
The figure below shows an example of correct wiring.
Note: If an motor safety switch or contactor is used, supply
either 2102
STOP FUNCTION [value must be 1 (COAST)] or 1608
START ENABLE 1 from an auxiliary contact of the isolator to the
ACH550.
Note: Wiring is discussed in more detail in chapter Installing the
drive.
