338 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
13 ANALOGUE MINIMUN AI1 1301 20.0% 20.0% 20.0% 20.0% 20.0% 20.0%
INPUTS
MAXIMUM AI1 1302 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
FILTER AI1 1303 0.1 s 0.1 s 0.1 s 0.1 s 0.1 s 0.1 s
MINIMUM AI2 1304 20.0% 20.0% 20.0% 20.0% 20.0% 20.0%
MAXIMUM AI2 1305 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
FILTER AI2 1306 0.1 s 0.1 s 0.1 s 0.1 s 0.1 s 0.1 s
14 RELAY
RELAY
OUTPUT 1
1401 READY STARTED STARTED STARTED STARTED STARTED
OUTPUTS
RELAY
OUTPUT 2
1402 RUN RUN RUN RUN RUN RUN
RELAY
OUTPUT 3 1403 FAULT (-1) FAULT (-1) FAULT (-1) FAULT (-1) FAULT (-1) FAULT (-1)
RO 1 ON
DELAY
1404 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 1 OFF
DELAY 1405 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 2 ON
DELAY
1406 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 2 OFF
DELAY
1407 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 3 ON
DELAY 1408 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 3 OFF
DELAY
1409 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RELAY
OUTPUT 4
1410 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
RELAY
OUTPUT 5
1411 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
RELAY
OUTPUT 6
1412 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
RO 4 ON
DELAY 1413 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 4 OFF
DELAY
1414 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 5 ON
DELAY
1415 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 5 OFF
DELAY
1416 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 6 ON
DELAY
1417 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
RO 6 OFF
DELAY 1418 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
