ABB ACH550-01 - Page 347

342 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
17 OVERRIDE
OVERRIDE
SEL 1701 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
OVERRIDE
FREQ
1702 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
OVERRIDE
SPEED
17030 rpm0 rpm0 rpm0 rpm0 rpm0 rpm
OVERR PASS
CODE1704000000
OVERRIDE 1705 OFF OFF OFF OFF OFF OFF
OVERRIDE
DIR 1706 FORWARD FORWARD FORWARD FORWARD FORWARD FORWARD
OVERRIDE
REF
1707 CONSTANT CONSTANT CONSTANT CONSTANT CONSTANT CONSTANT
20 LIMITS
MINIMUM
SPEED
2001 0 rpm 0 rpm 0 rpm 0 rpm 0 rpm 0 rpm
MAXIMUM
SPEED 2002 1500 rpm 1500 rpm 1500 rpm 1500 rpm 1500 rpm 1500 rpm
MAX
CURRENT
2003
1.1 · I
N
1.1 · I
N
1.1 · I
N
1.1 · I
N
1.1 · I
N
1.1 · I
N
UNDERVOLT
CTRL 2006
ENABLE
(TIME)
ENABLE
(TIME)
ENABLE
(TIME)
ENABLE
(TIME)
ENABLE
(TIME)
ENABLE
(TIME)
MINIMUM
FREQ
2007 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
MAXIMUM
FREQ
2008 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
MIN TORQUE
SEL 2013
MIN
TORQUE 1
MIN
TORQUE 1
MIN
TORQUE 1
MIN
TORQUE 1
MIN
TORQUE 1
MIN
TORQUE 1
MAX TORQUE
SEL
2014
MAX
TORQUE 1
MAX
TORQUE 1
MAX
TORQUE 1
MAX
TORQUE 1
MAX
TORQUE 1
MAX
TORQUE 1
MIN TORQUE
1
2015 -300.0% -300.0% -300.0% -300.0% -300.0% -300.0%
MIN TORQUE
2
2016 -300.0% -300.0% -300.0% -300.0% -300.0% -300.0%
MAX TORQUE
1
2017 300.0% 300.0% 300.0% 300.0% 300.0% 300.0%
MAX TORQUE
2 2018 300.0% 300.0% 300.0% 300.0% 300.0% 300.0%
21 START/
START
FUNCTION
2101 RAMP RAMP RAMP RAMP RAMP RAMP
STOP
STOP
FUNCTION
2102 COAST COAST COAST COAST COAST COAST
DC MAGN
TIME
2103 0.30 s 0.30 s 0.30 s 0.30 s 0.30 s 0.30 s
DC HOLD CTL2104NOT SELNOT SELNOT SELNOT SELNOT SELNOT SEL
DC HOLD
SPEED 21055rpm5rpm5rpm5rpm5rpm5rpm
DC CURR
REF
2106 30% 30% 30% 30% 30% 30%
DC BRAKE
TIME
2107 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
START
INHIBIT 2108 OFF OFF OFF OFF OFF OFF
EMERG STOP
SEL
2109NOT SELNOT SELNOT SELNOT SELNOT SELNOT SEL
TORQ BOOST
CURR 2110 100% 100% 100% 100% 100% 100%
START DELAY 2113 0.00 s 0.00 s 0.00 s 0.00 s 0.00 s 0.00 s
