344 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
22 ACCEL/
ACC/DEC 1/2
SEL 2201 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
DECEL
ACCELER
TIME 1
2202 30.0 s 15.0 s 15.0 s 30.0 s 10.0 s 5.0 s
DECELER
TIME 1
2203 30.0 s 15.0 s 15.0 s 30.0 s 10.0 s 5.0 s
RAMP SHAPE
1 2204 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
ACCELER
TIME 2
2205 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
DECELER
TIME 2 2206 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
RAMP SHAPE
2
2207 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
EMERG DEC
TIME
2208 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s
RAMP INPUT
0 2209 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
23 SPEED PROP GAIN 2301 5.00 5.00 5.00 5.00 5.00 5.00
CONTROL
INTEGRATION
TIME 2302 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s
DERIVATION
TIME
2303 0 ms 0 ms 0 ms 0 ms 0 ms 0 ms
ACC
COMPEN-
SATION 2304 0.00 s 0.00 s 0.00 s 0.00 s 0.00 s 0.00 s
AUTOTUNE
RUN
2305 OFF OFF OFF OFF OFF OFF
25 CRITICAL
CRIT SPEED
SEL
2501 OFF OFF OFF OFF OFF OFF
SPEEDS
CRIT SPEED
1 LO
2502
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
CRIT SPEED
1 HI
2503
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
CRIT SPEED
2 LO 2504
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
CRIT SPEED
2 HI
2505
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
CRIT SPEED
3 LO
2506
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
CRIT SPEED
3 HI 2507
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
0Hz /
0rpm
26 MOTOR
FLUX OPT
ENABLE
2601ONONONONONON
CONTROLS
FLUX
BRAKING 2602 OFF OFF OFF OFF OFF OFF
IR COMP
VOLT
26030 V0 V0 V0 V0 V0 V
IR COMP
FREQ
2604 80% 80% 80% 80% 80% 80%
U/F RATIO 2605 SQUARED SQUARED SQUARED SQUARED SQUARED SQUARED
SWITCHING
FREQ
2606 4 kHz 4 kHz 4 kHz 4 kHz 4 kHz 4 kHz
SWITCH
FREQ CTRL2607ONONONONONON
SLIP COMP
RATIO
26080%0%0%0%0%0%
NOISE
SMOOTHING
2609 DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE
DC
STABILIZER 2619 DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE
OVERMODUL
ATION
2625 DISABLE DISABLE DISABLE DISABLE DISABLE DISABLE
