ABB ACH550-01 - Page 359

354 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
37 USER LOAD
USER LOAD C
MODE 3701 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
CURVE
USER LOAD C
FUNC
3702 FAULT FAULT FAULT FAULT FAULT FAULT
USER LOAD C
TIME
3703 20 s 20 s 20 s 20 s 20 s 20 s
LOAD FREQ 1 3704 5 Hz 5 Hz 5 Hz 5 Hz 5 Hz 5 Hz
LOAD TORQ
LOW 1
3705 10% 10% 10% 10% 10% 10%
LOAD TORQ
HIGH 1 3706 300% 300% 300% 300% 300% 300%
LOAD FREQ 2 3707 25 Hz 25 Hz 25 Hz 25 Hz 25 Hz 25 Hz
LOAD TORQ
LOW 2
3708 15% 15% 15% 15% 15% 15%
LOAD TORQ
HIGH 2 3709 300% 300% 300% 300% 300% 300%
LOAD FREQ 3 3710 43 Hz 43 Hz 43 Hz 43 Hz 43 Hz 43 Hz
LOAD TORQ
LOW 3 3711 25% 25% 25% 25% 25% 25%
LOAD TORQ
HIGH 3
3712 300% 300% 300% 300% 300% 300%
LOAD FREQ 4 3713 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz
LOAD TORQ
LOW 4 3714 30% 30% 30% 30% 30% 30%
LOAD TORQ
HIGH 4
3715 300% 300% 300% 300% 300% 300%
LOAD FREQ 5 3716 500 Hz 500 Hz 500 Hz 500 Hz 500 Hz 500 Hz
LOAD TORQ
LOW 5
3717 30% 30% 30% 30% 30% 30%
LOAD TORQ
HIGH 5
3718 300% 300% 300% 300% 300% 300%
