358 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
41 PROCESS GAIN 4101 2.5 1.0 1.0 1.0 1.0 1.0
PID SET 2
INTEGRATION
TIME
4102 3.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
DERIVATION
TIME
4103 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s 0.0 s
PID DERIV
FILTER 4104 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s 1.0 s
ERROR
VALUE INV
4105NONONONONONO
UNITS4106%%%%%%
UNIT SCALE4107111111
0% VALUE 4108 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
100% VALUE 4109 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
SET POINT
SEL
4110 KEYPAD KEYPAD KEYPAD KEYPAD KEYPAD KEYPAD
INTERNAL
SETPNT 4111 40.0% 40.0% 40.0% 40.0% 40.0% 40.0%
SETPOINT
MIN
4112 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
SETPOINT
MAX
4113 100.0% 100.0% 100.0% 100.0% 100.0% 100.0%
FBK SEL 4114 ACT1 ACT1 ACT1 ACT1 ACT1 ACT1
FBK
MULTIPLIER
4115 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
ACT1 INPUT 4116 AI2 AI2 AI2 AI2 AI2 AI2
ACT2 INPUT 4117 AI2 AI2 AI2 AI2 AI2 AI2
ACT1
MINIMUM
4118 0% 0% 0% 0% 0% 0%
ACT1
MAXIMUM 4119 100% 100% 100% 100% 100% 100%
ACT2
MINIMUM
41200%0%0%0%0%0%
ACT2
MAXIMUM
4121 100% 100% 100% 100% 100% 100%
SLEEP
SELECTION
4122 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
PID SLEEP
LEVEL
4123 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz 0.0 Hz
PID SLEEP
DELAY 4124 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s 60.0 s
WAKE-UP
DEV
4125 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
WAKE-UP
DELAY
4126 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s
