ABB ACH550-01 - Page 371

366 Parameter listing and descriptions
ACH550-01 User's Manual
HVAC
default Supply fan Return fan
Cooling
tower fan Condenser
Booster
pump
Parameter
name
Par.
index
123456
81 PFA
REFERENCE
STEP 1 8103 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
CONTROL
REFERENCE
STEP 2
8104 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
REFERENCE
STEP 3
8105 0.0% 0.0% 0.0% 0.0% 0.0% 0.0%
START FREQ
1 8109 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
START FREQ
2
8110 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
START FREQ
3 8111 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz 50.0 Hz
LOW FREQ 1 8112 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz
LOW FREQ 2 8113 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz
LOW FREQ 3 8114 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz 25.0 Hz
AUX MOT
START D
8115 5.0 s 5.0 s 5.0 s 5.0 s 5.0 s 5.0 s
AUX MOT
STOP D 8116 3.0 s 3.0 s 3.0 s 3.0 s 3.0 s 3.0 s
NR OF AUX
MOT
8117111111
AUTOCHNG
INTERV
8118 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
AUTOCHNG
LEVEL 8119 50.0% 50.0% 50.0% 50.0% 50.0% 50.0%
INTERLOCKS 8120 DI4 DI4 DI4 DI4 DI4 DI4
REG BYPASS
CTRL
8121NONONONONONO
PFA START
DELAY
8122 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s 0.50 s
PFA ENABLE 8123 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
ACC IN AUX
STOP 8124 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
DEC IN AUX
START
8125 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
TIMED
AUTOCHNG
8126 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
MOTORS8127222222
AUX START
ORDER
8128
EVEN
RUNTIME
EVEN
RUNTIME
EVEN
RUNTIME
EVEN
RUNTIME
EVEN
RUNTIME
EVEN
RUNTIME
98 OPTIONS
COMM PROT
SEL 9802 NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL NOT SEL
