Technical data 399
ACH550-01 User's Manual
400 V drives
400 V drives (IP21 and IP54) can deliver following currents
continuously (24 hours a day, 7 days a week and 365 days a
year) in different ambient temperatures. These currents are
available up to 1000 m (3300 ft).
Type
Frame
size
P
40
I
35
I
40
I
45
I
50
M2000
ACH550-01- kWAAAA A
02A4-4 R1 0.75 2.5 2.4 2.3 2.2 1.93
03A3-4 R1 1.1 3.4 3.3 3.1 3.0 2.65
04A1-4 R1 1.5 4.2 4.1 3.9 3.7 3.50
05A4-4 R1 2.2 5.5 5.4 5.1 4.9 4.85
06A9-4 R1 3 7.0 6.9 6.6 6.3 6.30
08A8-4 R1 4 9.0 8.8 8.6 8.3 8.29
012A-4 R1 5.5 12.1 11.9 11.4 10.9 10.90
015A-4 R2 7.5 15.7 15.4 14.9 14.4 14.40
023A-4 R2 11 23.5 23.0 22.0 20.9 20.87
031A-4 R3 15 32 31 30 28 27.97
038A-4 R3 18.5 39 38 36 34 34.12
045A-4 R3 22 46 45 43 41 39.44
059A-4 R4 30 60 59 56 53 53
072A-4 R4 37 73 72 70 67 67
087A-4 R4 45 89 87 84 80 80
125A-4 R5 55 128 125 119 113 98
157A-4 R6 75 160 157 149 141 138
180A-4 R6 90 184 180 171 162 162
195A-4 R6 110 208 205 195 185 203
246A-4 R6 132 250 246 234 221 239
290A-4 R6 160 293 290 275 261 286
00467918.xls C
P
40
: Typical motor power at 40 °C
I
xx
: Drive output current at xx °C
M2000: ABB M2 motor nominal current
(Catalogue BU/General purpose
motors EN 12-2005)
