Technical data 403
ACH550-01 User's Manual
Fuses, 208…240 V drives
Note: The use of ultra rapid fuses is recommended, but normal
HRC fuses, ABB Tmax moulded case circuit breakers (MCCB)
or ABB S200 B/C miniature circuit breakers (MCB) are sufficient.
See section Circuit breakers on page 404.
ACH550-01-
Input
current
A
Mains fuses
IE 60269 gG
A
UL class T
A
Bussmann
type
1
04A6-2 4.6 10 10 JJS-10
06A6-2 6.6
07A5-2 7.5
012A-2 11.8 16 15 JJS-15
017A-2 16.7 25 25 JJS-25
024A-2 24.2 30 JJS-30
031A-2 30.8 40 40 JJS-40
046A-2 46 63 60 JJS-60
059A-2 59 80 JJS-80
075A-2 75 80 100 JJS-100
088A-2 88 100 110 JJS-110
114A-2 114 125 150 JJS-150
143A-2 143 200 200 JJS-200
178A-2 178 250 250 JJS-250
221A-2 221 315 300 JJS-300
248A-2 248 350 JJS-350
00467918.xls C
1
Example
